The X LITE 112 is a passive 2-way speaker designed for versatile sound reinforcement applications. Featuring a 12″ woofer with a 2.5″ voice coil and a 1″ compression driver with a 1.4″ voice coil, it delivers a maximum SPL of 126.5 dB with a frequency response from 55 Hz to 20 kHz. The cabinet is made from gas-injected molded polypropylene, ensuring a lightweight yet robust structure. It includes four M10 rigging points, a 35mm pole mount socket, and can also be used as a floor monitor thanks to its asymmetric shape. Designed for both fixed installations and portable setups, X-Lite 112 is equipped with two Neutrik NL4 speakon connectors and a steel grille for driver protection.
Technical Specifications
| Code |
46168 |
| Configuration |
2 ways |
| Recommended amplifier |
400W |
| Long Term power |
200W |
| Short term power |
800W |
| Nominal impedance |
8Ohm |
| Frequency response |
55Hz - 20kHz -6dB |
| Low Frequency woofer |
12'' - 2.5'' coil |
| High frequency driver |
1'' - 1.4'' coil |
| Sensitivity (@1W/1m) |
97dB |
| Maximum SPL cont/peak |
123.5 / 126.5dB |
| Dispersion |
90° x 60° HxV |
| Crossover Frequency |
1.8kHz |
| Recommended HP filter |
HP 45Hz - 12/24dB oct |
| Recommended external filter |
FBT DSP Processor |
| Input connector |
2 x Speakon NL4 |
| Net Dimension (WxHxD) |
352 x 619 x 356 mm / 13.8 x 24.3 x 14 inch |
| Net Weight |
15.2 Kg / 33.5 Lb |
