NEW | INSTALLED | X 28L | TWO-WAY LINE ARRAY MODULE | Technical Specifications | 140 dB max SPL
Technical Specifications
| Acoustical specifications |
| Frequency Response (-10dB) |
50 Hz - 20000 Hz |
| Max SPL @ 1m |
140 dB |
| Horizontal coverage angle |
110° |
| Vertical coverage angle |
20° |
| Power section |
| Amplification |
Full Range |
| Nominal Impedance |
8 ohm |
| Power Handling |
800 W RMS |
| Peak Power Handling |
3200 W PEAK |
| Protections |
Dynamic active mosfet |
| Crossover Frequencies |
750 Hz |
| Recommended Amplifiers |
XPS 16K, XPS 16KD |
| Transducers |
| Compression Driver |
1 x 1.4'' neo, 3.0'' v.c |
| Woofer |
2 x 8'' neo, 2.5'' v.c |
| Input/Output section |
| Input connectors |
Screw Terminals |
| Output connectors |
| Standard compliance |
| IP protection grade |
IP 55 |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Structural Polyurethane |
| Hardware |
Array fittings |
| Grille |
Aluminum with water-repellent protection |
| Color |
Black - RAL 9005 |
| Size / Weight |
| Height |
290 mm / 11.42 inches |
| Width |
658 mm / 25.91 inches |
| Depth |
378 mm / 14.88 inches |
| Weight |
24 kg / 52.91 lbs |
| Shipping information |
| Package Height |
390 mm / 15.35 inches |
| Package Width |
685 mm / 26.97 inches |
| Package Depth |
305 mm / 12.01 inches |
| Package Weight |
28.2 kg / 62.17 lbs |
