COMMERCIAL | UP 2162 | POWER AMPLIFIER | Power Amplifier designed for the transmission of announcements and / or musical programmes | Main input on removable connector | AUX Input for music sources removable connector
Technical Specifications
| Controls for treble, bass and Gain on the AUX Input |
| Technical Specifications |
Amplifier specifications |
| Output Power |
2 x 160 W @ 4 ohm |
| Frequency Response (-3dB) |
50 Hz - 16 Hz |
| Distortion (THD+N) @ 1 kHz nominal power |
<0.3 % |
| Input section |
Total number of inputs |
| 4 |
Balanced |
| Mono |
2 |
| Stereo |
Line inputs |
| Line connectors |
Euroblock |
| General Purpose Inputs (GPI) |
Output section |
| Power output connectors |
Processing |
| Tone controls |
Yes |
| Configuration and control |
Configuration |
| Front panel |
Priority |
| Protections |
Cooling |
| Convection |
Short circuit |
| Thermal |
DC |
| Fuses |
Power requirement |
| Operating voltage |
220-240/115 V~ 50/60Hz |
| Voltage selection |
Internal |
| Power consumption (MAX) |
700 W |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Metal |
| Color |
Black |
| Rack mounting |
19", 2U |
| Size / Weight |
| Height |
88 mm / 3.46 inches |
| Width |
442 mm / 17.4 inches |
| Depth |
230 mm / 9.06 inches |
| Weight |
7.22 kg / 15.92 lbs |
| Shipping information |
| Package Height |
200 mm / 7.87 inches |
| Package Width |
330 mm / 12.99 inches |
| Package Depth |
500 mm / 19.69 inches |
| Package Weight |
8.7 kg / 19.18 lbs |
