Description
RCF TRK PRO1 hardware interface packs a robust and well-thought USB 2.0 studio-in-a-box with all the connectivity required for microphones, musical instruments, or line-level signals to a computer running macOS or Windows. The internal linear preamp circuit allows the connection of 48V phantom-powered microphones and Hi-Z level instruments. The input signal can be routed to DAW (Digital Audio Workstation) at up to 24-bit, 192 kHz resolution. The interface can be connected to an amplifier and speakers, powered monitors, headphones, an analog mixer, or any other analog audio device.
Features
- 1 In 2 Out USB 2.0 Bus-Powered Audio Interface
- Up to 24-Bit/192kHz
- 1 Mic and Instrument/line Combo input
- High-quality preamp
- Balanced Output
- Independent headphone volume control
- Robust Metal Case
- Perfect for RDNet Measures
- 48V Phantom Power Supply
- Independent Gain Control with Signal-Peak LED
Specifications
| General specifications | |
| SUPPORTED BIT DEPTH | 16 Bit, 24 Bit |
| Standard compliance | |
| Safety agency | CE compliant |
| Physical specifications | |
| Cabinet/Case Material | Steel |
| Color | Black - RAL 9005 |
| Size / Weight | |
| Height | 46 mm / 1.81 inches |
| Width | 91.4 mm / 3.6 inches |
| Depth | 125.8 mm / 4.95 inches |
| Weight | 0.5 kg / 1.1 lbs |
| Shipping information | |
| Package Height | 80 mm / 3.15 inches |
| Package Width | 162 mm / 6.38 inches |
| Package Depth | 170 mm / 6.69 inches |
| Package Weight | 0.6 kg / 1.32 lbs |
