TOURING | SUB 9006-AS | ACTIVE HIGH POWER SUBWOOFER | Technical Specifications | 142 dB max SPL | 7200 Watt Peak power - 3600 Watt RMS
Technical Specifications
| Acoustical specifications |
| Frequency Response |
30 Hz - 400 Hz |
| Max SPL @ 1m |
142 dB |
| Transducers |
| Woofer |
2 x 18'' neo, 4.0'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
XLR, RDNet Ethercon |
| Output connectors |
Input sensitivity |
| +4 dBu |
| Processor section |
| Hi-Pass Frequencies |
30Hz, 40Hz |
| Low-Pass Frequencies |
Variable from 50Hz to 400Hz |
| Protections |
Thermal, RMS |
| Limiter |
Fast Limiter |
| Controls |
| Gain, EQ, Preset, Phase switch, Output Delay Settings |
Onboard |
| Power section |
| Total Power |
7200 W Peak, 3600 W RMS |
| Low frequencies |
Cooling |
| Convection/Forced |
| Connections |
| Powercon IN/OUT |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Baltic birch plywood |
| Hardware |
2 x M20 |
| Handles |
8 side |
| Pole mount/Cap |
M20 thread |
| Grille |
Steel |
| Color |
Black |
| Size / Weight |
| Height |
558 mm / 21.97 inches |
| Width |
1188 mm / 46.77 inches |
| Depth |
785 mm / 30.91 inches |
| Weight |
86 kg / 189.6 lbs |
| Shipping information |
| Package Height |
600 mm / 23.62 inches |
| Package Width |
835 mm / 32.87 inches |
| Package Depth |
1230 mm / 48.43 inches |
| Package Weight |
92 kg / 202.83 lbs |
