AYRA PRO5 Professional Active Two-Way Studio Monitors
AYRA PRO5 studio monitor works perfectly in any listening environment, whether large or small production facilities, with absolute clarity. It delivers accurate monitoring and provides the engineer or producer with a neutral tool to analyze recordings and optimize the mix; for this reason, we call it PRO. Featuring a dedicated powerful internal DSP that optimizes frequency response and dynamics together with the exclusive RCF FiRPHASE processing and selected components, the AYRA PRO is the first Studio Monitor in its class to boast an outstanding 0° phase response.
Features
- 50Hz - 20kHz Frequency Response
- 0° Phase Response
- 75W + 25W Class-D Amplifiers
- 5” Composite Fiberglass Woofer
- 1” ferrofluid cooled Soft Dome tweeter
- RCF Precision Waveguide
- DSP Processing with FiRPHASE
- Low distortion frontal Vented Ports
POWERFUL, COMPOSITE-CONE WOOFER
The AYRA PRO low-frequency drivers are accurately designed for a tight and true reproduction. The voice coil winding length is optimized for an extended low-frequency range. The composite fiberglass membrane cone design is the best choice for rigidity, damping and performance durability.
POTENT POWER AMPLIFIERS
Focus your creativity on your music at any volume. All AYRA PRO models are provided with high power and low distortion Two Class-D True Active low distortion amplifiers; the internal limiters will protect you from extreme clippings that can damage the transducers.
A NEW PERSPECTIVE ON LINEARITY
AYRA PRO is the first Studio Monitor in its class to boast an outstanding 0° phase response.
All models are designed with FiRPHASE, a proprietary and advanced FIR filtering technology, conceived for delivering transparent sound, absolute clarity and perfect stereo images to the listener. A dedicated powerful internal DSP optimizes frequency response and dynamics with exclusive RCF FiRPHASE processing.
More about this product?
Specifications
Acoustical specifications
| Frequency Response |
50 Hz - 20000 Hz |
| Max SPL @ 1m |
110 dB |
| Horizontal coverage angle |
110° |
| Vertical coverage angle |
70° |
Transducers
| Dome Tweeter |
1.0'' neo, 1.0'' v.c |
| Woofer |
1 x 5.0'', 1.0'' v.c |
Input/Output section
| Input signal |
bal/unbal |
| Input connectors |
XLR, Jack, RCA |
| Input sensitivity |
-2 dBu/+4 dBu |
Processor section
| Crossover Frequencies |
2000Hz |
| Limiter |
Soft Limiter |
Power section
| Total Power |
200 W Peak, 100 W RMS |
| High frequencies |
50 W Peak, 25 W RMS |
| Low frequencies |
150 W Peak, 75 W RMS |
| Connections |
XLR, Jack, RCA |
Standard compliance
| Safety agency |
CE compliant |
Physical specifications
| Cabinet/Case Material |
MDF |
| Color |
Black - RAL 9005 |
Size / Weight
| Height |
300 mm / 11.81 inches |
| Width |
185 mm / 7.28 inches |
| Depth |
243 mm / 9.57 inches |
| Weight |
4.3 kg / 9.48 lbs |
Shipping information
| Package Height |
400 mm / 15.75 inches |
| Package Width |
339 mm / 13.35 inches |
| Package Depth |
261 mm / 10.28 inches |
| Package Weight |
6 kg / 13.23 lbs |
