JMAZ PIXL FX BAR 5050 180W RGB / CWW LED Effect Bar

The JMAZ PIXL FX BAR 5050 is a 180W RGB/CWW LED effect bar featuring 60W warm white LED beams, 48W RGB SMD LEDs, and 72W cool white inner SMD LEDs. With a narrow 3° beam angle, it offers 10 built-in auto sound programs and 8 sound programs. DMX512 compatible with powerCON in/out, it includes a powerCON cable, stand mount, and DMX cable, making it ideal for dynamic lighting effects. No remote included.

Main Features

• 60W (12 x 5W) Warm White LED Beams
• 48W (96 x 0.5W) RGB SMD LEDs
• 72W (144 x 0.5W) Cool White Inner SMD LEDs
• Beam Angle: 3°
• 10 Built-In Auto Sound Programs
• 8 Sound Programs
• Protocols: 3-Pin In/Out DMX512
• powerCON In/Out
• Included: powerCON Cable, Stand Mount, DMX Cable
• No Remote

Technical Specifications

Light Source

• 12 x 5W Warm White LED Beams
• 96 x 0.5W RGB SMD LEDs
• 144 x 0.5W Cool White Inner SMD LEDs

Color System

• Warm White LEDs
• RGB SMD LEDs
• CW SMD LEDs

Optics

• Beam Angle: 3°

Dynamic Effect

• 10 Built-In Auto Sound Programs

8 Sound Programs

• RGB Wash Effect

Strobe

Beam Effect

• Dynamic RGB

Zone Control

Control

• Protocols: DMX512
• Personalities: 6 Modes 10/18/23/28/33/65

Electronics

• Dimmer: 0-100% Linear Dimmer

Strobe

Body

Die-Cast Aluminum Alloy

Physical

• powerCON In/Out

Electrical

• Max Power Consumption: 150W
• 1 x User Manual
• 1 x Stand Mount
• 1 x DMX Cable
• 1 x powerCON Cable

Item Dimensions & Weight

• Dimensions: 39.4″ x 2.8″ x 2.9″
• Weight: 8.6 lbs

Warranty

2 Years
