DMR-19: Display Mount for Racks

Adjustable-depth display mount for 19 inch E.I.A. two-post and four-post racks, is made to hold a flat panel display or LCD monitor that features a standard VESA 75mm or 100mm hole pattern. The mount is ideal for AV or security installations, control rooms, and similar applications.

FEATURES

• 14-gauge steel center plate with multiple access points
• 16-gauge steel mounting ears
• Black finish
• Width:  19 in.
• Depth:  5.2 in.
• Height:  6.97 in. (4U)
• Assembly hardware
• Load capacity 40 lbs.

COMPLIANCE & CERTIFICATION

• Certified U.S. steel
• Made in Missouri, U.S.A.

A&E SPECIFICATIONS

•  The rack shall include a display-mounting panel, Lowell model DMR-19, to accommodate a flat panel display or monitor that has a standard VESA 75mm or 100mm hole pattern (display/monitor not included). The E.I.A. compliant unit shall feature a center plate with multiple access points and rack-mounting ears. It shall be made in the U.S.A. with certified U.S. steel and have a smooth black powder epoxy finish. Overall measurements shall be 6.97 in. high (4U) x 5.20 in. deep x 19 in. wide. Load capacity shall be 40 lbs.
