- 12-inch LF SMX woofer
- 1.25-inch HF titanium compression driver
- 2000 W Class-D power amplifier with integrated FIR-Drive DSP
- 135 dB peak SPL
Building upon the legendary heritage of Electro-Voice audio engineering, ETX are designed to be the most advanced professional-grade portable loudspeakers available today. The series combines intelligent FIR-Drive technology with innovative industrial design to deliver stunning performance and unbeatable versatility in the most demanding applications. EV-engineered components ensure superior sound quality and the utmost reliability.
| Frequency Response (-3 dB) |
55 Hz - 20 kHz |
| Frequency Range (-10 dB) |
43 Hz - 20 kHz |
| Maximum SPL |
135 dB peak |
| Coverage (H x V) |
90° x 60° |
| Power Rating |
2000 W |
| LF Transducer |
SMX2120 300 mm (12 in) |
| HF Transducer |
DH3-B 1.25-in titanium compression driver |
| Crossover Frequency |
1600 Hz |
| Connectors |
(2) XLR/TRS combo jack and (1) XLR link output |
| Enclosure |
18mm Plywood with EVCoat |
| Grille |
16AWG steel with powdercoat |
| Suspension |
(8) M10 suspension points |
| Dimensions (H x W x D) |
613 mm x 381 mm x 400 mm (24 in x 15 in x 16 in) |
| Net Weight |
23.6 kg (52.0 lb) |
| Shipping Weight |
26.8 kg (59.1 lb) |
| Power Consumption |
100 - 240 V~, 50 - 60 Hz, 1.6 - 0.8 A |
