Description
Resolution software delivers system prediction, control and monitoring from any location in the venue.
Proven EAW acoustical design and DSP including Focusing™ and DynO™ provides a pristine impulse response at all output levels.
Four pre-de ned voicings provide a variety of tonal starting points.
Integrated Dante™ networking (with loop-thru) on all models including Analog redundancy capability.
Specifications
Frequency Response: 70 Hz -20 kHz
Max SPL: 128 dB
Operating Mode: Bi-amp (LF/HF); DSP w/EAW Focusing™and DynO™
Subsystem: LF - 1 x 8 in cone, 2 in voice coil HF - 1 x 1 in exit, 1.4 in voice coil compression driver
Nominal Beamwidth: Horizontal 90° Vertical 60°
Power Handling: LF: 500W HF: 500W
Connections: Powercon AC Mains/Loop 2x Neutrik® etherCON™ RJ-45 XLR Input/Loop
Dimensions: Height: 19.61 in (498 mm) Width: 12.40 in (315 mm) Depth: 12.83 in (326 mm)
Weight: 40 lbs (15.1 kg)
