Description
Instantly convert any USB-C disk into network storage! Includes 10G Ethernet for high performance and HDMI status monitoring, and Blackmagic Cloud sync for distributing files globally.
Blackmagic Cloud Dock Share disks over 10G Ethernet for editing and global media sharing! Blackmagic Cloud Dock lets you mount media disks from cameras and directly share your media files globally with editors and colorists over a fast 10G Ethernet network without waiting for files to copy! The Blackmagic Cloud Dock syncs and shares media from any SSD disk with Blackmagic Cloud. It even understands proxy workflows, so a whole timeline and its media can be shared in minutes. It features high speed 10G Ethernet connections for extremely fast file access, even with multiple users connected. File access is very low latency, so responsiveness is fast. That's why it's the perfect solution for sharing media files between editors, colorists, audio engineers and VFX artists!
Designed for Film and Television Blackmagic Cloud Dock will transform customer's work! It's perfect for film and television because you can record onto SSDs including the super fast U.2 NVMe disks and then use the Blackmagic Cloud Dock to make the disks available on the network for multiple editors and colorists to use. Depending on the brand of SSD used, it even handles massive 12K Blackmagic RAW digital cinema files! SSDs such as the latest 7mm U.2 NVMe disks are super fast, delivering data transfer speeds of up to 900 MB/s! Blackmagic Cloud sync allows you to place docks in different locations so everyone can have a fast local copy of their files. Then each location gets the fastest editing experience possible.
Blackmagic Cloud Dock 2 Share up to 2 independent SSDs or U.2 disks on your network. Includes 2 x 10G Ethernet ports and HDMI for status monitoring. Blackmagic Cloud sync allows the distribution of files globally.
Share up to 4 independent SSDs or U.2 disks on your network. Includes 4 x 10G Ethernet ports and HDMI for status monitoring. Blackmagic Cloud sync allows the distribution of files globally.
Blackmagic Cloud Dock features a compact rack mount design so it is easy to install in a studio with other network equipment or in a DIT cart on-set to immediately mount and share camera files with editors and colorists globally. It features up to four SSD slots so it can host separate SSD disks on your network at the same time. 10G Ethernet ports means you get extremely high performance. There is also an HDMI monitoring output so you can watch a live graphic view of the storage operating on a TV or monitor. Each slot has an LED status light that shows disk activity, so you know when the disk is being accessed. Plus it's easily repairable with each card slot using an individual PCB assembly!
1. AC Power An IEC power socket is included for connecting AC power. All international AC voltages are supported so you can use it globally.
Specifications
Connections
- 10G Ethernet Ports: 1 x Ethernet supports 100/1000/10G BASE-T
- USB-C Port: 2 x USB 3.0 (up to 5Gb/s) for external storage.
- HDMI Monitor Outputs: 1
- Computer Interface: Ethernet for shared file access, configuration and software updates. USB-C for configuration and software updates.
File Sharing Protocol
- Protocol: NFS SMB
- Computer Connections: 50 max.
Storage
- Storage Type: Bring your own drive
- External Storage: USB Disks
- External Storage Format: ExFAT (Windows/Mac) or HFS+ (Mac) file systems.
Displays
- HDMI Monitor Out Standards: 1080p50, 1080p59.94, 1080p60
- Monitor Out Displays: Device Name, storage capacity and use, Cloud Sync status, User Activity, Hardware Status, storage map, network data rate graphs.
- Status Indicator: Glow strip illuminates red during read or write operations.
Device Control
- External Control: USB-C or Ethernet for configuration and software updates.
Software
- Software Included: Blackmagic Cloud Setup Utility Blackmagic Proxy Generator Lite Internal software upgrade via Blackmagic Cloud Setup using USB-C port.
Environmental Specifications
- Operating Temperature: 0° to 40° C (32°to 104° F)
- Storage Temperature: -20° to 60° C (-4° to 140° F)
- Relative Humidity: 0% to 90% non-condensing
Physical
- Weight: 1.91 lb
