The Behringer SD16 is a 16-channel digital stage box with 16 remote-controllable Midas-designed mic preamps and 8 outputs, connecting to an X32 or Wing console over AES50 with Klark Teknik SuperMAC. It integrates with Powerplay P16 personal monitoring and offers a streamlined, rugged way to add stage I/O over a single Cat 5 cable.
Features
- 16 remote-controllable Midas-designed mic preamps
- 8 outputs
- AES50 networking with Klark Teknik SuperMAC
- Ultranet integration with Powerplay P16 systems
- Single Cat 5 cable connection to console
- Rugged, streamlined stage-box design
Specifications
| Type |
Digital stage box |
| Inputs |
16 Midas mic preamps |
| Outputs |
8 |
| Networking |
AES50 (SuperMAC) |
| Monitoring |
Ultranet / P16 |
| Dimensions (W x D x H) |
13.11 x 5.87 x 5.51 in (333 x 149 x 140 mm) |
| Weight |
7.04 lb (3.19 kg) |
| UPC |
4033653070454 |
