The Behringer DR18SUB is a 2400 W active 18" PA subwoofer with a Class-D amplifier and onboard DSP, built to add deep, high-output low frequencies to a full-range system. A built-in stereo crossover offers Link and Xover output modes with a switchable 90/120 Hz cutoff, plus level and phase controls and an RMS/peak limiter for driver protection. It reaches up to 129 dB SPL over a 30 to 150 Hz range and includes a 35 mm pole socket for mounting satellite tops.
Features
- 2400 W Class-D amplifier with state-of-the-art DSP
- 18" long-excursion subwoofer driver
- Built-in stereo crossover with Link and Xover modes
- Switchable crossover cutoff (90 / 120 Hz)
- Up to 129 dB SPL over 30 - 150 Hz
- Balanced XLR inputs and outputs, level and phase controls
- RMS and peak limiter; 35 mm pole socket for satellite tops
Specifications
| Type |
Active PA subwoofer |
| Woofer |
18" long-excursion |
| Amplifier Power |
2400 W Class-D |
| Frequency Range |
30 - 150 Hz |
| Max SPL |
129 dB |
| Crossover |
Built-in stereo, 90/120 Hz cutoff |
| Output Modes |
Link / Xover |
| Connections |
Balanced XLR in / out |
| Dimensions (W x D x H) |
20.87 x 23.98 x 25.59 in (530 x 609 x 650 mm) |
| Weight |
90.2 lb (40.91 kg) |
| UPC |
4033653231497 |
