JMAZ ATTCO BEAM 230W OSRAM Moving Head

The JMAZ ATTCO BEAM 230 features a powerful 231W OSRAM SIRIUS HRI discharge lamp, delivering up to 164,230 lux at 10m. It includes an 11-color wheel, 16 static gobos, dual prism wheels, and a frost filter for versatile effects. With a 2.5° beam angle, electronic focus (2.5m-30m), and DMX512 or RF remote control, it’s ideal for impactful lighting. Includes RF remote, Omega bracket, powerCON, DMX cable, and safety accessories.

Main Features

• 231W OSRAM SIRIUS HRI Discharge Lamp
• Lux: 164,230 lx @ 10m , 73,170 lx @ 15m
• Color Wheel: 11 Colors + Open
• Static Gobos: 16 + Open
• Dual Prism Wheel: Frist Prism 16 Facet , Second 8 Facet + 16 w/ Variable Speed
• Frost Filter
• Electronic Focus: 2.5m-30m
• Beam Angle: 2.5°
• Protocols: 3-Pin In/Out DMX512, Wireless DMX, RF Remote
• 9 Built-In Auto/Sound Programs
• powerCON In/Out
• Included: RF Remote, Omega Bracket, powerCon Cable, DMX Cable, Safety Cable, Manual

Technical Specifications

Light Source

• 231W OSRAM SIRIUS HRI Discharge Lamp
• Lux: 164,230 lx @ 10m , 73,170 lx @ 15m
• Life Expectancy: 2,000 hrs

Color System

• Color Wheel: 11 colors + Open

Optics

• Beam Angle: 2.5°
• Electronic Motorized Focus: 2.5m-30m
• Lens Diameter: 136mm
• Lens Type: Anti-Reflections

Dynamic Effect

• Static Gobos: 16 + Open
• Dual Prism Wheel: Frist Prism 16 Facet , Second 8 Facet + 16 w/ Variable Speed
• 9 Built-In Auto/Sound Programs

Frost Filter

• Dual Flag Mechanical Dimming

Control

• Protocols: 3-Pin In/Out DMX512, Wireless DMX
• Personalities: 2 Modes 14/16
• Wireless Control: RF Remote
• Display: 2.4″ TFT LCD Display

Electronics

• Dimmer:0-100% Linear Dimmer
• Operating Temperature:-35° C to 45° C

Body

Quick-Lock Omega Bracket

• Pan Angle: 630°
• Title Angle: 270°
• High Temperature Engineered Plastic and Cast Aluminum Casing

Physical

• Cooling: Fan
• Pan/Tilt: 8/16 bit smooth
• powerCON In/Out

Electrical

• Max Power Consumption: 190W
• Input Voltage: AC91-260V, 50/60Hz
• 2 x Omega Brackets
• 1 x DMX Cable
• 1 x powerCON Cable
• 1 x RF Remote
• 1 x Safety Cable
• 1 x User Manual

Item Dimensions & Weight

• Dimensions: 15.2″ x 15″ x 8.7″
• Weight: 30.6 lbs
• Black: 093674449565
• White: 618528606989

Warranty

2 Years
