Description
The CS3 BU is the base unit for the CS3 conference system and provides all the necessary inputs and outputs to manage a conference for up to 60 microphone stations. It is the interface to all audio devices in a meeting room and offers a RS232 interface to connect an optional camera control system. The CS3 BU can even work in a stand-alone mode in four selectable operating modes offering maximum flexibility in conference management. With the NOM limitation function, the maximum number of active stations can be programmed to 1, 2, 4 or 6 simultaneous open microphones.
Features
- All in one conference controller
- For discussion systems of up to 60 stations per base unit
- Four selectable operating modes
- For flexible conference management
- Connects to all relevant devices
- e.g. PA, recording, ext. audio and camera control systems
- Compact 19" housing
- For easy rack mounting
Specifications
- Power Supply: SMPS 100-240V (50Hz / 60 Hz) 3A
- Static Consumption: 13W
- Nominal Power Consumption: 320W
- Output Power: ≤90W / 24V each way
- Mode: Balanced / Unbalanced
- Frequency Response: 50Hz-20kHz
- S/N: >80dB
- Harmonic Distortion: <0.5%
- Harmonic Distortion at Overload: <1%
- Crosstalk Attenuation (1kHz): >50dB
- Operating Temperature: 0°C - 40°C at 95% relative humidity (non-condensing)
- Length: 482 mm
- Width: 281 mm
- Height: 88.4 mm
- Weight: 5.2kg
