Description
Main Features:
Launch your creations in Ultra-HD
Drive your visual inspirations with clarity. The UHD-100A simplifies the creation of video content that requires Ultra-HD quality, ranging from telemedicine to machine vision in its smallest form.
Specification
Video
Image Sensor
1/2.5″ Progressive CMOS
Sensor Size
Diagonal 7.20mm
Effective Pixels
Horizontal: 3840, Vertical: 2160
Pixel Size
1.62 µm (H) x 1.62 µm (V)
Resolution
2160 30p/29.97p/25p/24p 1080 60p/59.94p/50p/30p/ 29.97p/25p/24p 1080 60i/59.94i/50i 720 60p/59.94p/50p/30p/25p
Output
HDMI 1.4
Color Space
4:2:2 (YCbCr) 10bit
Function
White Balance
AWB / AE / AF
Exposure
Full Auto, Bright, Shutter Priority, Iris Priority, Manual
Other
WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction,
Digital Slow Shutter, Black Level Compensation, Flicker Detection
Lens
C/CS Mount (Default UHD 3.2mm Lens)
Audio
Input
3.5mm TRS Stereo Mic-in & Line in over I/O Cable
Sample Rate
16/24/32 Bits
Physical
Camera Control
RS-485 VISCA, OSD Button
Operation Temp
32° F - 104° F
Dimension
39mm x 39mm x 50.50mm / 1.53″ x 1.53″ x 1.99
Weight
140g / 0.30lbs
Power
12VDC (+9 - +15VDC)
Downloads
Operation Manual
Firmware
Diagram
[metaslider id=”9194″]
Additional Details
- Weight: 2.0 lb
- Shipping Dimensions (L x W x D): 10x5x4 in
- Country of Origin: KR
- UPC: 682863380156
