Description
Main Features:
Pan. Tilt. Zoom. Repeat.
Pan-Tilt-Zoom cameras has revolutionized video productions by reducing camera operators to one, while producing the most demanding live production shoots. The PTZ-X20-IP offers a wide array of simultaneous HD video and direct stream with audio embedment to various streaming platforms while delivering superb images with a 20X optical zoom. Ideal for broadcast applications, huddle rooms, houses of worship and more.
Specification
Video
Image Sensor
1/2.5″ Progressive CMOS
Effective Pixels
Horizontal: 1920, Vertical: 1080
Pixel Size
2.13 µm x 2.13 µm
Resolution
1080p & 1080i: 1920 x 1080
Resolution | Rate
108060p/59.94p/50p/30p/29.97p/25p/24p/23.98p
1080 60i/59.94i/50i
720 60p/59.94p/50p/30p/29.97p/25p
IP Rate
1920 x 1080 @ 1~60
1280 x 720 @ 1~60
1024 x 576 @ 1~60
620 x 360 @ 1~60
Output
HD-SDI/3G-SDI
HDMI
RJ45
USB 3.0 & 2.0
Color Space
4:2:2 (YCbCr) 10bit
Min. Illumination
0.1Lux
Function
White Balance
Auto, Manual, Auto Tracking, One Push, Indoor, Outdoor
Focus
Auto, Manual
Shutter Speed
1 to 1/10,000 Sec.
Lens
20X HD Optical Zoom, F1.5 ~ F3.0
Pan, Tilt :Range
Pan: 340°,
Tilt: +90 to -30°
Pan, Tilt :Speed
Pan: 0° to +120°/s
Tilt: 0° to +80°/s
Presets
128 Positions
Field of View
Standard
SMPTE
SMPTE 292M, SMPTE 424M
IP Protocol
TCP|IP, RTSP|RTMP
Audio
Input
3.5mm TRS Stereo Audio Port
Sample Rate
16/24/32 Bits
Physical
Camera Control
Protocol: VISCA
Interface: RS-232C IN & OUT, RJ-45
Remote Controller
Operation Temp
32° F - 104° F
Dimension
155mm x 160m x 170mm / 6.10″ x 6.92″ x 6.69″
Weight
1.35kg / 2.97lbs
Power
12VDC (+9 - +15VDC)
PoE+ (IEEE802.3at Standard Required)
Downloads
Operation Manual
Firmware
Diagram
