Description
Main Features:
Reducing camera operators to one!
PTZ cameras are the bread and butter of dynamic live production shots. It doesn’t matter where the PTZ is placed, this camera will see it all. Equipped with 12x optical zoom, the PTZ-NDI-X12 has a plethora of camera features, ranging from camera control to simultaneous Full-HD Outputs to NDI|HX. This camera was made for broadcast application, huddle rooms, or houses of worship. When it comes to the PTZ-NDI-X12 to step up to the plate, we can guarantee you it will perform.
Specification
Video
Image Sensor
1/2.5″ Progressive CMOS
Effective Pixels
Horizontal: 1920, Vertical: 1080
Pixel Size
2.13 µm x 2.13 µm
Resolution
1080p & 1080i: 1920 x 1080
Resolution | Rate
108060p/59.94p/50p/30p/29.97p/25p/24p/23.98p
1080 60i/59.94i/50i
720 60p/59.94p/50p/30p/29.97p/25p
IP Rate
1920 x 1080 @ 1~60
1280 x 720 @ 1~60
1024 x 576 @ 1~60
620 x 360 @ 1~60
Output
HD-SDI/3G-SDI
HDMI
RTSP / RTMP / NDI®|HX
USB 3.0 & 2.0
Color Space
4:2:2 (YCbCr) 10bit
Min. Illumination
0.1Lux
Function
White Balance
Auto, Manual, Auto Tracking, One Push, Indoor, Outdoor
Focus
Auto, Manual
Shutter Speed
1 to 1/10,000 Sec.
Lens
12X HD Optical Zoom, F1.5 ~ F3.0
Pan, Tilt :Range
Pan: 340°,
Tilt: +90 to -30°
Pan, Tilt :Speed
Pan: 0° to +120°/s
Tilt: 0° to +80°/s
Presets
128 Positions
Field of View
72.5°
Standard
SMPTE
SMPTE 292M, SMPTE 424M
IP Protocol
TCP|IP, RTSP|RTMP
Audio
Input
3.5mm TRS Stereo Audio Port
Sample Rate
16/24/32 Bits
Physical
Camera Control
Protocol: VISCA
Interface: RS-232C IN & OUT, RJ-45
Remote Controller
Operation Temp
32° F - 104° F
Dimension
155mm x 160m x 170mm / 6.10″ x 6.92″ x 6.69″
Weight
1.35kg / 2.97lbs
Power
12VDC (+9 - +15VDC)
PoE+ (IEEE802.3at Standard Required)
Downloads
Operation Manual
Firmware
Diagram
[metaslider id=”9309″]
Additional Details
- Weight: 9.0 lb
- Shipping Dimensions (L x W x D): 12x12x12 in
- Country of Origin: KR
- UPC: 682863380125
