Description
Main Features:
In the mood to be outdoors
Introducing the camera where no other AIDA products have gone before; the outdoors. Indulge in almost any environment with IP67 rated protection, covering against dust, moisture, and even water submersion up to 1m for 30 minutes. These are ideal characteristics for all-weather sporting events, professional biology research, and OB vehicles looking for that next scoop.
Specification
Video
Image Sensor
1/3″ Progressive CMOS
Sensor Size
Diagonal 7.20mm
Effective Pixels
Horizontal: 1920, Vertical: 1080
Pixel Size
2.75 μm (H) x 2.75 μm (V)
Resolution
1080p / 1080i : 1920 x 1080
720p : 1280 x 720
Resolution | Rate
1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25 / 24
1080i : 60 / 59.94 / 50i 720
720p : 60 / 59.94 / 50p
Output
3G-SDI
Color Space
4:2:2 (YCbCr) 10bit
Function
White Balance
AWB / AE / AF
Exposure
Full Auto, Bright, Shutter Priority, Iris Priority, Manual
Other
WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction,
Digital Slow Shutter, Black Level Compensation, Flicker Detection
Lens
3X Optical Zoom Lens, 3.85mm/78° (Wide) ~ 13.4mm/25° (Tele)
Standard
SMPTE
SMPTE 292M, SMPTE 424M
Physical
Weatherproof Rating
IP67
Camera Control
RS-485
OSD Button
Operation Temp
32°F - 104°F
Dimension
48mm x 48mm x 83.09mm / 1.89″ x 1.89″ x 3.27″
Weight
140g / 0.30lbs
Power
12 VDC (+9 - +15VDC)
Downloads
Operation Manual
Diagram
[metaslider id=”9037″]
Additional Details
- Weight: 3.0 lb
- Shipping Dimensions (L x W x D): 10x5x4 in
- Country of Origin: KR
- UPC: 686091739779
