| Active or Passive |
Active |
| Program Power (Watts) |
6500 Watts Program (13000 Watts Peak) |
| Measured Max SPL (C-Weighted, Max Hold) |
130 dB Cont. 136 dB Peak |
| Frequency Response (Hz +/- 3dB) |
31Hz-100Hz |
| Crossover Frequency (Hz) |
100 Hz lowpass |
| Cabinet Configuration |
Bass Reflex |
| Driver Configuration |
3x15" LF woofer |
| LF Driver(s) |
15" Ceramic with 3" Voice Coil |
| LF Program Power(Watts) |
6500 Watts Program (13000 Watts Peak) |
| LF Impedance (Ohms) |
2.7 ohm Load (3x 8 ohm) |
| LF Protection |
Excursion, Voice Coil Thermal (RMS) |
| LF Power Amplifier (Watts) |
6500 Watts Program (13000 Watts Peak) |
| LF Amplifier Type |
Class D |
| Cooling Scheme |
Convection |
| Power Cable |
Removable Locking Powercon True Input and Loop Thru Output |
| Power Switch |
Yes |
| Power Consumption (typ/max) |
600 VA / 1200 VA |
| Inputs |
1 XLR with 2x XLR Parallel out, Impedance 35k ohms |
| Input Sensitivity (Vrms Sine) |
Line in 1.4 at center, 0.56 at max |
| Level Controls |
Volume, -?,0dB,8dB (Min, Top, Max) |
| EQ Controls |
Thermal Limiter Advance for power consumption management |
| Limiter |
Excursion, Thermal (RMS), Clipping |
| LED Indicators |
Power, Excursion Limit, Thermal (RMS) Limit, Input Clip, Activity |
| Enclosure Materials |
Multiply 15mm Birch Plywood |
| Standard Rigging Hardware |
RAIL and LOCKBAR Rigging System (Top and Bottom) |
| Stacking Feature |
Interlocking UHMW Feet (Top and Bottom) |
| Covering / Finish |
Paint |
| Dimensions (DWH xbackW, inches) |
24 x 21 x 51.5 x 12.25 |
| Dimensions (DWH xbackW, cm) |
60.9 x 53.3 x 130.8 x 31.1 |
| Weight (lbs/kg) |
236/107 |
