| Active or Passive |
Active |
| Program Power (Watts) |
6000 Watts Program (17000 Watts Peak) |
| Measured Max SPL (C-Weighted, Max Hold) |
130.6 dB Cont. 142.6 dB Peak |
| Frequency Response (Hz +/- 3dB) |
28 - 100Hz |
| Crossover Frequency (Hz) |
50/100 lowpass |
| Cabinet Configuration |
Bass Reflex |
| Driver Configuration |
2x21" LF woofer |
| LF Driver(s) |
21" Neo with 4.5" Tetra Coil |
| LF Program Power(Watts) |
6000 Watts Program (17000 Watts Peak) |
| LF Impedance (Ohms) |
2 ohm Load (2 x 4 ohm) |
| LF Protection |
Excursion, Voice Coil Thermal (RMS) |
| LF Power Amplifier (Watts) |
6000 Watts Program (17000 Watts Peak) |
| LF Amplifier Type |
Class D |
| Cooling Scheme |
Convection |
| Power Cable |
Removable Locking Powercon True Input and Loop Thru Output |
| Power Switch |
Yes |
| Power Consumption (typ/max) |
1440 VA / 1920 VA |
| Inputs |
1 XLR with 2x XLR Parallel out, Impedance 35k ohms |
| Input Sensitivity (Vrms Sine) |
Line in 1.4 at center, 0.56 at max |
| Level Controls |
Volume, -?,0dB,8dB (Min, Top, Max) |
| EQ Controls |
Thermal Limiter Advance for power consumption management |
| Limiter |
Excursion, Thermal (RMS), Clipping |
| LED Indicators |
Power, Excursion Limit, Thermal (RMS) Limit, Input Clip, Activity |
| Enclosure Materials |
Multiply 15mm Birch Plywood |
| Stacking Feature |
Rubber Feet and Cups (Side and Bottom) |
| Covering / Finish |
Paint |
| Other Details |
4 x Locking Swivel Casters On Rear Of Cabinet, 2 Stand Adapters (1 Top, 1 Side) |
| Dimensions (DWH xbackW, inches) |
32.75 (37.75 including casters) x 29.75 x 47.5 |
