ARCHIVED | TT+ | TOURING | TT 25-A II | ACTIVE HIGH OUTPUT TWO-WAY SPEAKER | 1100 W Class D Amplifier
Technical Specifications
| Acoustical specifications |
| Frequency Response |
50 Hz - 20000 Hz |
| Max SPL @ 1m |
134 dB |
| Horizontal coverage angle |
90° |
| Vertical coverage angle |
60° |
| Transducers |
| Compression Driver |
1 x 1.5'' neo, 4.0'' v.c |
| Woofer |
1 x 15'' neo, 3.5'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
XLR, RDNet Ethercon |
| Output connectors |
Input sensitivity |
| -2 dBu/+4 dBu |
| Processor section |
| Crossover Frequencies |
750 Hz |
| Protections |
Thermal, HF |
| Limiter |
Fast Limiter |
| Controls |
| Proces., 8 sel. presets |
Onboard |
| Power section |
| Total Power |
2200 W Peak, 1100 W RMS |
| High frequencies |
600 W Peak, 300 W RMS |
| Low frequencies |
1600 W Peak, 800 W RMS |
| Cooling |
Convection |
| Connections |
| Powercon IN/OUT |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Baltic birch plywood |
| Hardware |
6xfly track, quick lock, pole mount |
| Handles |
2 on side |
| Grille |
Steel |
| Color |
Black |
| Size / Weight |
| Height |
670 mm / 26.38 inches |
| Width |
425 mm / 16.73 inches |
| Depth |
Weight |
| 26 kg / 57.32 lbs |
| Shipping information |
| Package Height |
715 mm / 28.15 inches |
| Package Width |
470 mm / 18.5 inches |
| Package Depth |
Package Weight |
| 32.7 kg / 72.09 lbs |
