SUB 18-AX | PROFESSIONAL ACTIVE 18" SUBWOOFER | 2200 Watt Class-D Amplifier | Technical Specifications | 135 dB MAX SPL | 18” Woofer, bass reflex housing
Technical Specifications
| Acoustical specifications |
| Frequency Response |
35 Hz - 120 Hz |
| Max SPL @ 1m |
135 dB |
| Transducers |
| Woofer |
1 x 18'', 4.0'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
Combo XLR/Jack |
| Output connectors |
XLR |
| Input sensitivity |
-2 dBu/+4 dBu |
| Processor section |
| Protections |
Thermal |
| Limiter |
Soft Limiter |
| Controls |
| Encoder for Volume control and data entry. Touch Screen for parameter management and monitor. |
| Power section |
| Total Power |
2200 W Peak, 1100 W RMS |
| Cooling |
Convection |
| Connections |
| Powercon TRUE1 TOP IN/OUT |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Plywood |
| Handles |
1 handle per side |
| Pole mount/Cap |
M20 thread |
| Grille |
Steel |
| Color |
Black, White |
| Size / Weight |
| Height |
693 mm / 27.28 inches |
| Width |
505 mm / 19.88 inches |
| Depth |
685 mm / 26.97 inches |
| Weight |
42.9 kg / 94.58 lbs |
| Shipping information |
| Package Height |
735 mm / 28.94 inches |
| Package Width |
745 mm / 29.33 inches |
| Package Depth |
565 mm / 22.24 inches |
| Package Weight |
49 kg / 108.03 lbs |
