TOURING | SUB 8004-AS | ACTIVE HIGH POWER SUBWOOFER | 2500 Watt Peak | 18" Woofer, 4.0" voice coil vented woofer | Technical Specifications
Technical Specifications
| Acoustical specifications |
| Frequency Response |
30 Hz - 120 Hz |
| Max SPL @ 1m |
136 dB |
| Transducers |
| Woofer |
1 x 18'', 4.0'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
XLR |
| Output connectors |
Input sensitivity |
| -2 dBu/+4 dBu |
| Processor section |
| Hi-Pass Frequencies |
120 Hz |
| Low-Pass Frequencies |
90 Hz |
| Protections |
Thermal, RMS |
| Limiter |
Fast Limiter |
| Controls |
| Xover, Phase switch, Deep/Punch, Outuput Delay Settings, Cardioid |
| Power section |
| Total Power |
2500 W Peak, 1250 W RMS |
| Low frequencies |
Cooling |
| Convection |
| Connections |
| Powercon IN/OUT |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Baltic birch plywood |
| Hardware |
Provision for four wheel mounting on the rear panel. |
| Handles |
One handle each side |
| Pole mount/Cap |
M20 thread |
| Grille |
Steel with clothing |
| Color |
Black |
| Size / Weight |
| Height |
700 mm / 27.56 inches |
| Width |
558 mm / 21.97 inches |
| Depth |
Weight |
| 56 kg / 123.46 lbs |
| Shipping information |
| Package Height |
761 mm / 29.96 inches |
| Package Width |
751 mm / 29.57 inches |
| Package Depth |
612 mm / 24.09 inches |
| Package Weight |
60 kg / 132.28 lbs |
