TOURING | NXW 44-A | ACTIVE TWO-WAY COLUMN SPEAKER | Up to 135 dB Sound Pressure Level | 2100W Class-D Amplifier | 100° x 50° Constant Directivity Coverage Angle
Technical Specifications
| Acoustical specifications |
| Frequency Response |
45 Hz - 20000 Hz |
| Max SPL @ 1m |
135 dB |
| Horizontal coverage angle |
100° |
| Vertical coverage angle |
50° |
| Transducers |
| Compression Driver |
1 x 1.4'' neo, 3.0'' v.c |
| Woofer |
3 x 10'' neo, 2.5'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
Combo XLR/Jack |
| Output connectors |
XLR |
| Input sensitivity |
-2 dBu/+4 dBu |
| Processor section |
| Crossover Frequencies |
800 |
| Protections |
Thermal, Excurs., RMS |
| Limiter |
Soft Limiter |
| Controls |
| Linear/Boost/High-Pass presets, Volume |
| Power section |
| Total Power |
2100 W Peak |
| High frequencies |
700 W Peak |
| Low frequencies |
1400 W Peak |
| Cooling |
Convection |
| Connections |
| Powercon TRUE1 TOP IN/OUT |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Baltic birch plywood |
| Hardware |
8 x M8, 8 x quick lock |
| Handles |
2 side |
| Pole mount/Cap |
35 mm insert |
| Grille |
Steel |
| Color |
Black |
| Size / Weight |
| Height |
1080 mm / 42.52 inches |
| Width |
297.5 mm / 11.71 inches |
| Depth |
373 mm / 14.69 inches |
| Weight |
31.55 kg / 69.56 lbs |
| Shipping information |
| Package Height |
400 mm / 15.75 inches |
| Package Width |
1115 mm / 43.9 inches |
| Package Depth |
327 mm / 12.87 inches |
| Package Weight |
33.65 kg / 74.19 lbs |
