Description
Tile Rail for 4' x 4' Ceiling Tiles MTC-48TRx12 is an accessory tile rail for installing many of JBL’s ceiling loudspeakers into 4 ft by 4 ft (1200 x 1200 mm; 48 x 48 inch) ceiling tiles in suspended ceiling applications.
Features
- Can be used with any JBL ceiling speakers having the C-ring/tile-rail mounting system. Includes (at product release): • Control 24C/CT Micro & 24CT MicroPlus • Control 24C/CT, 26C/CT, 19CS/CST • Control 47C/T, 47LP, 47HC, 40CS/T, 42C • Control 226C/T • 8124/8128 • Not for JBL speakers that install with tile bridges (such as CSS Series, 8138, C227C/CT, C300 Series models). Check with JBL Professional Customer Service for most up-to-date compatibility list.
- Inverted V-groove provides support to the tile rail grid in case of tile failure while reducing vibration transfer to - and rattling from - ceiling tile grid system.
- 1.2 mm (0.05 in) metal thickness provides the additional support required by the long span.
- Multiple C-ring mounting holes. Additional hole locations drillable by installer.
- One MTC-48TRx12 is a pack of 12 tile rails, enough for 6 speakers (2 per speaker).
Specifications
- Model: MTC-48TRx12
- Material: 1.2 mm (0.05 in, 18 gauge) galvanized steel, SECC.
- C-Ring MountingHoles: 30 holes; additional hole locations drillable by installer.
- Dimensions (HxWxL): 27 mm (1.1 in) x 30 mm (1.2 in) x 1267 mm (49.9 in) to extend beyond tile grids. 1219 mm (48.0 in) between top of inverted v-grooves, to line up with tile grids.
- Weight: 20.35 lb
- Dimensions (L x W x H): 9 x 48 x 3.5 in
- UPC: 691991300066
- Country of Origin: CN
