COMMERCIAL | HD 410T | ALUMINIUM HORN SPEAKER WITH DRIVER AND TRANSFORMER | Built-in line transformer with multitap power selector on rear cover | Hi-pass filter for protecting driver against out-of-range low-freq | IP 66 construction for indoor-outdoor environmental temperature between -25°C to +70°C
Technical Specifications
| Acoustical specifications |
| Frequency Response (-10dB) |
180 Hz - 7000 Hz |
| Max SPL @ 1m |
130 dB |
| Coverage angle |
90° |
| System Sensitivity |
112 dB |
| Power section |
| Amplification |
Full Range |
| Power Handling |
50 W |
| Peak Power Handling |
200 W PEAK |
| Transducers |
| Compression Driver |
1 x 2.0'' |
| Input/Output section |
| Input connectors |
Cable |
| Output connectors |
Constant Voltage Transformer |
| 70/100 V |
Power selection 1 |
| 50 W - 200 ohm |
Power selection 2 |
| 30 W - 333 ohm |
Power selection 3 |
| 25 W - 400 ohm |
Power selection 4 |
| 15 W - 667 ohm |
Power selection 5 |
| 7.5 W - 1333 ohm |
| Standard compliance |
| IP protection grade |
IP 66 |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Aluminum |
| Hardware |
Stainless steel U bracket |
| Color |
Grey - RAL 7035 |
| Size / Weight |
| Depth |
393 mm / 15.47 inches |
| Diameter |
430 mm / 16.93 inches |
| Weight |
3.57 kg / 7.87 lbs |
| Shipping information |
| Package Height |
415 mm / 16.34 inches |
| Package Width |
420 mm / 16.54 inches |
| Package Depth |
Package Weight |
| 6.06 kg / 13.36 lbs |
