NEW | EVOX J9 | ACTIVE THREE-WAY PORTABLE COLUMN SPEAKER | Technical Specifications | 130 dB Max SPL | 2100 W Class-D Amplifier - Built-In DSP
Technical Specifications
| Acoustical specifications |
| Frequency Response |
40 Hz - 20000 Hz |
| Max SPL @ 1m |
130 dB |
| Horizontal coverage angle |
120° |
| Vertical coverage angle |
40° |
| Transducers |
| Compression Driver |
1 x 0.75'' neo, 1.75'' v.c |
| Fullrange |
6 x 3.0'' neo, 1.0'' v.c |
| Woofer |
1 x 12'', 2.5'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
Combo XLR/Jack |
| Output connectors |
XLR |
| Input sensitivity |
-2 dBu/+4 dBu |
| Processor section |
| Crossover Frequencies |
200 Hz/1800 Hz |
| Protections |
Thermal, RMS |
| Limiter |
Soft Limiter |
| Controls |
| Volume, Presets: LINEAR/LIVE, CLUB, VOICE |
| Power section |
| Total Power |
2100 W Peak |
| High frequencies |
700 W Peak |
| Low frequencies |
1400 W Peak |
| Cooling |
Convection |
| Connections |
| VDE |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
PP Composite |
| Handles |
1 Top |
| Pole mount/Cap |
Quick-fit socket |
| Grille |
Steel |
| Color |
Black, White - RAL 9003 |
| Size / Weight |
| Height |
2080.1 mm / 81.89 inches |
| Width |
350 mm / 13.78 inches |
| Depth |
462.6 mm / 18.21 inches |
| Weight |
28.3 kg / 62.39 lbs |
| Shipping information |
| Package Height |
680 mm / 26.77 inches |
| Package Width |
490 mm / 19.29 inches |
| Package Depth |
460 mm / 18.11 inches |
| Package Weight |
32 kg / 70.55 lbs |
