EAW SM12 White, Passive 12in Coaxial Stage Monitor, 1 x 12in 2.5in Voice Coil LF and 1 x 1in Exit 44mm" Voice Coil HF, Horizontal 90 Vertical 60
Roll over image to zoom in Click on image to zoom
EAW SM12 White, Passive 12in Coaxial Stage Monitor, 1 x 12in 2.5in Voice Coil LF and 1 x 1in Exit 44mm" Voice Coil HF, Horizontal 90 Vertical 60

EAW SM12 White, Passive 12in Coaxial Stage Monitor, 1 x 12in 2.5in Voice Coil LF and 1 x 1in Exit 44mm" Voice Coil HF, Horizontal 90 Vertical 60

EAWSKU: 2071624-90
Price:
$2,412.00

Description

2-Way 12″ Stage Monitor Inspired by the Microwedge acoustic design, SM12 is the latest addition to EAW’s robust catalog of stage monitors.

Features Include:

  • High output, coaxial stage monitor.
  • Patented CSA coaxial horn provides superior control, fidelity and output.
  • Integrated kickstand supports alternative deployment angle.
  • Multiple input options improves cable management utilizing fewer cable runs
  • Companion UXA4403 amplifier.
  • Passive operation for maximumamplifier utilization.

Specifications

Frequency Response: 60Hz-20kHz

Max SPL: 135dB

Operating Mode: Single-Amp (LF/HF, DSP w/ EAW Focusing & DynO)

Subsystem: LF Transducer, Loading 1×12″ cone, 2.5″ VC, Vented HF Transducer, Loading 1×1-in exit, 44mm voice coil compression driver, Concentric Summation Array (CSA) loaded

Nominal Beamwidth: 90 x 60 degress, rotatable

Power Handling: 600W @ 8ohms

Connections: 4x Nuetrik NL4 (2x on bottom, 2x inside port)

Dimensions: 12.8 x 14.1 x 21.5in (326 x 357 x 546mm)

Weight: 35 lbs (15.9kg)
