Description
Resolution software delivers system prediction, control and monitoring from any location in the venue.
Proven EAW acoustical design and DSP including Focusing™ and DynO™ provides a pristine impulse response at all output levels.
Four pre-defined voicings provide a variety of tonal starting points.
Integrated Dante™ networking (with loop-thru) on all models including Analog redundancy capability.
Specifications
Frequency Response: 48 Hz -20 kHz
Max SPL: 135 dB
Operating Mode: Amplifier Channels: Bi-amp (LF/HF) Signal Processing: DSP w/EAW Focusing™and DynO™
Subsystem: Transducer: LF - 1 x 12 in cone, 3 in voice coil HF - 1 x 1 in exit, 1.7 in voice coil compression driver
Nominal Beamwidth: Horizontal 90° Vertical 60°
Power Handling: LF: 500W HF: 500W
Connections: Powercon AC Mains/Loop 2x Neutrik® etherCON™ RJ-45 XLR Input/Loop
Dimensions: Height: 26.89 in (683.0 mm) Width: 16.30 in (414.0 mm) Depth: 16.50 in (419.0 mm)
Weight: 66 lb (30 kg)
