VOICE ALARM EN54 | COMMERCIAL | INSTALLED | DU 50EN | WALL AND CEILING UNIVERSAL STEEL SPEAKER | 5" fullrange transducer.
Technical Specifications
| Acoustical specifications |
| Frequency Response (-10dB) |
190 Hz - 18000 Hz |
| Max SPL @ 1m |
100 dB |
| Max SPL @ 4m |
88 dB |
| Coverage angle |
175° |
| System Sensitivity |
91 dB |
| System Sensitivity 1W @ 4m |
79 dB |
| Power section |
| Power Handling |
6 W |
| Peak Power Handling |
24 W PEAK |
| Protections |
Thermal fuse |
| Recommended Amplifiers |
DXT 3000, DXT 4000, DXT 7000 |
| Transducers |
| Fullrange |
1 x 5.0'' |
| Input/Output section |
| Input connectors |
Ceramic screw terminals |
| Output connectors |
Constant Voltage Transformer |
| 100 V |
Power selection 1 |
| 6 W - 1667 ohm |
Power selection 2 |
| 3 W - 3333 ohm |
Power selection 3 |
| 1.5 W - 6667 ohm |
Power selection 4 |
| 0.75 W - 13333 ohm |
| Standard compliance |
| Safety agency |
CE compliant |
| EN54-24 certified |
Yes |
| CPR number |
1488-CPR-0489/W |
| Physical specifications |
| Cabinet/Case Material |
Metal |
| Grille |
Steel |
| Color |
White - RAL 9010 |
| Size / Weight |
| Height |
164 mm / 6.46 inches |
| Width |
Depth |
| 60 mm / 2.36 inches |
Weight |
| 1.9 kg / 4.19 lbs |
| Shipping information |
| Package Height |
70 mm / 2.76 inches |
| Package Width |
185 mm / 7.28 inches |
| Package Depth |
180 mm / 7.09 inches |
| Package Weight |
3.2 kg / 7.05 lbs |
