BUSINESS MUSIC | INSTALLED | COMPACT M 04 | TWO-WAY PASSIVE SPEAKER | 60W RMS power handling | Technical Specifications
Technical Specifications
| Acoustical specifications |
| Frequency Response (-10dB) |
90 Hz - 20000 Hz |
| Max SPL @ 1m |
113 dB |
| Horizontal coverage angle |
120° |
| Vertical coverage angle |
Directivity index Q |
| 6 |
System Sensitivity |
| 89 dB |
| Power section |
| Amplification |
Full Range |
| Nominal Impedance |
16 ohm |
| Power Handling |
60 W |
| Peak Power Handling |
240 W PEAK |
| Crossover Frequencies |
1800 Hz |
| Recommended Amplifiers |
DMA 162, DMA 162P, DMA 504, DMA 82 |
| Transducers |
| Dome Tweeter |
1 x 1.0'' neo, 1.0'' v.c |
| Woofer |
1 x 4.0'', 1.0'' v.c |
| Input/Output section |
| Input connectors |
Euroblock |
| Output connectors |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
Plywood |
| Hardware |
2 x M6, 2 x M8 |
| Grille |
Steel with clothing |
| Color |
Black - RAL 9005, White - RAL 9003 |
| Size / Weight |
| Height |
148 mm / 5.83 inches |
| Width |
132 mm / 5.2 inches |
| Depth |
145 mm / 5.71 inches |
| Weight |
2.3 kg / 5.07 lbs |
| Shipping information |
| Package Height |
168 mm / 6.61 inches |
| Package Width |
233 mm / 9.17 inches |
| Package Depth |
150 mm / 5.91 inches |
| Package Weight |
2.9 kg / 6.39 lbs |
