ART 732-A MK5 | ACTIVE TWO-WAY SPEAKER | Technical Specifications | 131 dB Max SPL | 1400 WATT 2-way peak power | 90° x 60°, Wide dispersion constant directivity horn
Technical Specifications
| Acoustical specifications |
| Frequency Response |
50 Hz - 20000 Hz |
| Max SPL @ 1m |
131 dB |
| Horizontal coverage angle |
90° |
| Vertical coverage angle |
60° |
| Transducers |
| Compression Driver |
1 x 1.4'' neo, 3.0'' v.c |
| Woofer |
1 x 12'', 2.5'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
XLR, Jack |
| Output connectors |
XLR |
| Input sensitivity |
-2 dBu/+4 dBu |
| Mic. Input Sensitivity |
-32 dBu |
| Processor section |
| Crossover Frequencies |
700 |
| Protections |
Thermal, RMS |
| Limiter |
Soft Limiter |
| Controls |
| Volume, Boost, MIC/Line |
| Power section |
| Total Power |
1400 W Peak |
| High frequencies |
400 W Peak |
| Low frequencies |
1000 W Peak |
| Cooling |
Convection |
| Connections |
| VDE |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
PP Composite |
| Hardware |
2 x M10 |
| Handles |
1 on top, 1 each side |
| Pole mount/Cap |
35 mm insert |
| Grille |
Steel |
| Color |
Black |
| Size / Weight |
| Height |
637 mm / 25.08 inches |
| Width |
387 mm / 15.24 inches |
| Depth |
363 mm / 14.29 inches |
| Weight |
17.8 kg / 39.24 lbs |
| Shipping information |
| Package Height |
680 mm / 26.77 inches |
| Package Width |
440 mm / 17.32 inches |
| Package Depth |
420 mm / 16.54 inches |
| Package Weight |
20.6 kg / 45.42 lbs |
