ART 710-A MK5 | ACTIVE TWO-WAY SPEAKER | XBOOST Low Frequencies Enhancer | Technical Specifications | 129 dB Max SPL | 1400 WATT 2-way peak power
Technical Specifications
| Acoustical specifications |
| Frequency Response |
50 Hz - 20000 Hz |
| Max SPL @ 1m |
129 dB |
| Horizontal coverage angle |
90° |
| Vertical coverage angle |
70° |
| Transducers |
| Compression Driver |
1 x 1.0'', 1.75'' v.c |
| Woofer |
1 x 10'', 2.5'' v.c |
| Input/Output section |
| Input signal |
bal/unbal |
| Input connectors |
XLR, Jack |
| Output connectors |
XLR |
| Input sensitivity |
-2 dBu/+4 dBu |
| Mic. Input Sensitivity |
-32 dBu |
| Processor section |
| Crossover Frequencies |
1600 |
| Protections |
Thermal, RMS |
| Limiter |
Soft Limiter |
| Controls |
| Volume, Boost, MIC/Line |
| Power section |
| Total Power |
1400 W Peak |
| High frequencies |
400 W Peak |
| Low frequencies |
1000 W Peak |
| Cooling |
Convection |
| Connections |
| VDE |
| Standard compliance |
| Safety agency |
CE compliant |
| Physical specifications |
| Cabinet/Case Material |
PP Composite |
| Hardware |
2 x M10 |
| Handles |
1 on top |
| Pole mount/Cap |
35 mm insert |
| Grille |
Steel |
| Color |
Black |
| Size / Weight |
| Height |
548 mm / 21.57 inches |
| Width |
340 mm / 13.39 inches |
| Depth |
305 mm / 12.01 inches |
| Weight |
14.2 kg / 31.31 lbs |
| Shipping information |
| Package Height |
585 mm / 23.03 inches |
| Package Width |
425 mm / 16.73 inches |
| Package Depth |
405 mm / 15.94 inches |
| Package Weight |
16.8 kg / 37.04 lbs |
