Description
The American DJ CVT4K is built as a high-performance fiber converter that is professionally developed by NovaStar independently. It comes featuring a photoelectric conversion of signals, the CVT4K is realizing the signal transmission with the use of optical fiber and twisted pair. It is designed allowing the long-distance signal transmission that is stable and not be easily interfered. Being easy to use, the CVT4K is designed making it convenient for connecting terminal devices as well as simpler for onsite wiring connections.
Features
- Supports 16 Neutrik Ethernet inputs and outputs
- Supports 4 optical fiber inputs and outputs. Two of them are master inputs and outputs and the other two are the backups
- Features dual-power redundancy backup inside for more stability and reliability
- Features 2 types of power connectors (3-pin power socket and PowerCON), satisfying different needs of customers.
- Features various indicators on the front panel, showing device statuses clearly
- Features USB and Ethernet control connectors, making it more flexible and much easier to connect the control computer
Specifications
- Input Voltage: 100–240 VAC, 50/60 Hz
- Rated Power Consumption: 10 W
- Operating Temperature: –20°C to 60°C
- Storage Temperature: –20°C to 70°C
- Operating Humidity: 10%–90% RH
- Dimensions: 19.69x15.20x3.78 in. (500.0×386.0×96.0 mm)
- Net Weight: 10.14 lbs. (4.6 kg)
- Certifications
- CE
- RoHS
- FCC
- UL&CUL
- EAC
- CB
- IC
